MY "VANDA"

“Vanda” a Sanskrit word describing the various epiphytic orchids constituting the genus vanda, which are native to tropical Asia and especially cultivated for their showy flowers, so named in 1793 by Sir William Jones, a lawyer and founder of the Asiatic Society (SOED)

Home: About

Home: Image

Brief Details

Home Port/Flag

Hong Kong S.A.R, China

Official Number

HK-1101

Call Sign

VR-YY7

MMSI

477676000

Tonnage

Gross 213.74t (604.89cm)

Register

136.48t (386.24cm)

Length overall

35.5 / 116 feet

Waterline length

31.1m / 102 ft

Main Engines

2 x Cummins V12T-800M

Speed

12 knots

Home: List

Home: Image

Draught and Displacement

3.26m / 10.69 ft mean, light ship – displacement 220 tons
3.62m / 11.85 ft with full fuel/water – displacement 258 tons

Air draught: 17.2m (13.6m without radio antennae)

Generators

Main: 2 x Caterpillar 75 kVA
Standby: Kohler 24 kVA

Emergency power: Deutz/Stamford 30 kVA

All generators 400 volts 3 phase 50 Hz

Owner’s/Guest Accommodation

2 double staterooms, 2 twin cabins, all with bathroom en suite
2 bunk cabin for children/staff, office with pilot bunk on main deck.

Crew Accommodation

Captain’s cabin, 2 double bunk cabins, 4 bunk cabin
2 Showers/WC.

Home: List

History & Hull

“Vanda” (ex “Van Triumph”) was built in Hong Kong in 1975 by Supercraft Ltd. as a private yacht for the yard’s owner, and maintained in class with American Bureau of Shipping, with Machinery Certificate. She was renamed after the launch of his new 65m Van Triumph. In 1993 she was laid up ashore at Supercraft’s yard in Hong Kong, where she was maintained by them until a suitable idiot like the present owner was found to buy her in 2003.

Home: Welcome

Machinery
Electrical System
Pumps System
Piping System

Home: About

Safety Equipment
Boats
Ground tackle
Deck Fittings

Home: About

Bridge & Navigation

Electronic & Navigational Equipment

Home: About

Galley & Domestic Equipment

Main Deck Galley

Double deep sink with small waste sink and macerator.
SMEG LPG range with 4 rings, and electric grill and convection oven underneath
Halogen and 2 microwave ovens
Fischer Paykal dishwashing machine
Refrigerator and freezer, 18cu ft
Coffee Maker
RO FW filter
Air conditioner (SW cooled from engine room)
Deep Freeze - 12 cu ft drawer deep freeze, 220v/or 24v thru inverter

Crew Galley

Toshiba 10 cu. Ft refrigerator freezer, 220v/24v
Dometic 4 cu ft fridge, 24v
Frigeco 6 cu ft deep freeze, 24v
Induction cooker, and microwave
Twin tub washing machine
Digital TV (Thai)

Bar Equipment

Bottle Cooler – “ International”, water circulation type, 8 dozen capacity, 220v AC
“Oasis” hot and cold water dispenser, 220v AC
U-Line 35 Ice Maker (230v AC) , 10 Kg (550 cubes) per day, with separate filtered water supply
